A‑Tip^®,ELD^®Match,ELD‑X^®, andELD‑VT^®Ballistic Coefficient Values

Hornady originally published “800 yard”* average Ballistic Coefficient (BC) values forELD‑XandELD Matchbullets. This was done to provide the most usable BC from a trajectory prediction standpoint. Unfortunately, many shooters did not understand that Hornady was listing a more useable “800 yard” BC while other manufacturers list “200 yard”* BCs. When doing pre‑purchase research either on the web or at the store, the increased performance of the ELD Match and ELD‑X bullets wasn’t always realized in a head‑to‑head BC comparison.

Newly Published base of comparison

Hornady now publishes “200 yard”Mach 2.25(2,512 fps @ ICAO Standard Atmosphere**) G1 and G7 Ballistic Coefficient (BC) numbers for all A‑Tip®, ELD‑X, and ELD Match bullets.Mach 2.0(2,233 fps @ ICAO Standard Atmosphere) andMach 1.75(1,954 fps @ ICAO Standard Atmosphere) BC values are also available.

As Hornady moves the industry todrag coefficient based trajectory calculationsfor these types of projectiles, the Ballistic Coefficient is becoming somewhat irrelevant. Exceptions are for those still using BC based trajectory calculators or when using BC as rating criteria for bullet performance.

Ballistic Coefficient (BC) values atMach 2.25(2512 fps @ ICAO Standard Atmosphere) should be used when comparing to other published BC values within the industry. Ballistic Coefficient values atMach 1.75(1954 fps @ ICAO Standard Atmosphere), should be used when calculating trajectories for shooting beyond 600 yds. Ballistic Coefficient values at Mach 2.0 and 1.75 offer comparisons to other manufacturers that publish multiple BC’s based on velocity.

A Positive Gain

In addition to the change listed above, a select few ELD‑X and ELD Match bullets initially had BC values that were determined from prototype bullets. As Hornady moved into production of these bullets, the BC value increased (a positive gain) due to the improvements in the manufacturing process from R&D to production machinery.

TheScienceBehind It

Ballistic Coefficient (BC) values can, and usually do change in value with changes in velocity. Most bullets exhibit a lowering BC as velocity slows. The extent of how much a BC will change depends on each unique bullet shape. When comparing BCs of different bullets, it is important to use an apples‑to‑apples approach.

To do this, bullets should be compared at a given Mach number (e.g. Mach 1 = 1116.48 fps @ ICAO Standard Atmosphere). Mach number is the velocity of the bullet divided by the speed of sound. If a Mach number is unavailable, velocity can be used if the BCs are corrected to Standard Atmosphere which is fairly typical practice within the industry.

The majority of industry published BCs is measured over relatively short ranges of 100 to 300 yards, which corresponds to velocities around 2500 fps depending on muzzle velocities. Some manufacturers offer BC values at different velocity ranges.
